All in one POS terminal touchscreen Cleo
| Model | Cleo R | Cleo E |
|---|---|---|
| Display | 10.1″, Resolution 1280 x 800 (250 nits) 14“, Resolution 1366 x 768 ( 220 nits) |
|
| Touch | PCAP Touch | |
| CPU | Intel® Celeron® Processor J6412 (Elkhart Lake) | Rockchip RK3568 |
| Memory | DDR4 4GB, 8GB, 16GB | DDR4 4GB |
| Storage | M.2 PCIe SSD: 128G / 256G / 512G | eMMc 64GB + 1x Micro SD Card Slot |
| External I/O Interface | ||
| 4 x USB 3.2 + 2 x USB 2.0 | ||
| 4 x Serial ports, RS232 (RJ45), 0V/5V/12V selected in BIOS (COM1, COM2, COM3, COM4) | 4 x Serial Ports, RS232 (RJ45), 0V/5V/12V Selection by UI (COM1, COM2, COM3, COM4) | |
| 1 x LAN (IEEE 802.3 10/ 100/ 1000 Mbps Ethernet, RJ45) | ||
| 1 x RJ11 port supports 2 Cash drawers with 24V / 12V by jumper setting | ||
| 1 x Audio (1 x line out) | ||
| 1 x HDMI 2.1 | ||
| 1 x DC + 24V input | ||
| N/A | 1 x Micro SD card | |
| Speaker | 1 x Speaker (3W) | |
| Printer | 3″ Thermal Printer | |
| Optional Peripheral | ||
| MSR(Beep), IC Card Reader, Fingerprint, RFID | ||
| 2D Barcode Scanner | ||
| 5MP Camera | ||
| USB 2nd Display | ||
| WIFI/BT(option) | IEEE 802.11 a/b/g/n/acR2/axR2, BT5.2 | IEEE 802.11 a/b/g/n/ac/ax, BT 5.0 (on board) |
| Display Support | 3 Independent Displays (Main Display + HDMI + CD-101C) | 2 Independent Displays (Main Display + CD-101C or HDMI) |
| Spill & Dust resistant | N/A | |
| Operating System | ||
| 1. Windows 11 IoT Enterprise AC (64bit) | Android 12 | |
| 2. Windows 10 IoT Enterprise LTSC 21H2 (64bit) and newer version | Android 12 | |
| 3. Linux (Ubuntu 22.04) | Android 12 | |
| TPM | H/W TPM 2.0 | N/A |
| Power Adaptor | AC-In 100~240V / DC-Out 24V, 72W | |
| Reliability | ||
| System Operating Temperature:0~40°C (32~104°F) | ||
| System Humidity: 15% ~ 80% | ||
| Storage Temperature: -20~60°C (-4~140°F) | ||
| Dimensions (Wx Hx D) | 340.64 x 315.19 x 247.13 mm / 13.41x 12.41 x 9.73 inch | |
| Weight | 3.3 Kgs / 7.28 Ibs | |
